EZVIZ H9c Dual-Lens Pan & Tilt 4G Outdoor Security Camera
The
EZVIZ H9c 4G revolutionizes outdoor property surveillance by combining revolutionary dual-lens imaging with dependable
4G LTE cellular connectivity. Designed specifically for areas without reliable Wi-Fi or wired network access—such as construction sites, farms, warehouses, remote holiday homes, and perimeter gates—the H9c 4G ensures round-the-clock peace of mind wherever power is available.
Equipped with a synchronized dual-lens system, the top fixed lens continuously oversees a wide panoramic view, while the bottom motorized pan-and-tilt lens actively patrols and tracks subjects. When the wide-angle camera identifies human or vehicular movement, the pan-and-tilt camera automatically rotates and zooms in to capture crystal-clear details in stunning 3K Ultra HD resolution.
Key Features:
- 4G LTE Cellular & Wi-Fi Connectivity: Operates seamlessly using a Nano-SIM card on 4G LTE mobile networks with dual-band Wi-Fi and RJ45 Ethernet support, ensuring flexible connectivity anywhere.
- Revolutionary Dual-Lens System: Upper wide-angle lens (manually rotatable 240° horizontally, 15° tilt) provides non-stop panoramic oversight, while lower PT lens (350° pan, 80° tilt) provides dynamic tracking.
- Co-Detection & Smart Auto-Tracking: Both lenses work in intelligent synergy—the upper lens detects a target and instantly directs the lower PTZ lens to lock on and follow movement.
- 3K Ultra HD Clarity: Delivers sharp 2880 × 1620 resolution, capturing facial features, clothing, and vehicle number plates with lifelike detail.
- Smart AI Human & Vehicle Detection: On-device AI algorithms recognize human and vehicle shapes, significantly reducing false triggers caused by insects, rain, or swaying foliage.
- Full-Color Night Vision up to 40 Meters: High-power spotlight illumination delivers vibrant, full-color nighttime video up to 40m, with black-and-white infrared night vision reaching up to 30m.
- Two-Way Talk with Voice Changer: Hear and speak to visitors in real time via high-fidelity microphone and speaker, with an optional voice disguise feature for enhanced personal safety.
- Active Defense Siren & Strobe Light: Automatically triggers a piercing 100 dB alarm siren and flashes dual high-intensity spotlights upon detecting intruders.
- All-Weather Outdoor Design: Weatherproof housing withstands rain, wind, dust, and extreme temperature conditions (-30°C to 50°C).
- Flexible High-Capacity Storage: Supports MicroSD cards up to 512 GB as well as encrypted EZVIZ CloudPlay storage.
Technical Specifications:
- Model: CS-H9c-R105-8H55WFL4GA (H9c 4G Dual-Lens)
- Image Sensor: 1/2.7” Progressive Scan CMOS (Upper & Lower lenses)
- Resolution: Dual 3K (2880 × 1620) @ 15fps
- Lens Specifications:
- Upper Lens: 2.8mm @ F1.6 (FOV: Diagonal 130°, Horizontal 108°, Vertical 56°)
- Lower Lens: 6mm @ F1.6 (FOV: Diagonal 62°, Horizontal 54°, Vertical 29°)
- PT Angle: Pan: 350°, Tilt: 80° (Motorized lower lens)
- Cellular Network: 4G LTE (FDD/TDD) via standard Nano-SIM card
- Wired & Wireless Network: 1 × RJ45 10M/100M Ethernet port, 2.4 GHz Wi-Fi
- Video Compression: H.265 / H.264 Main Profile
- Night Vision Range: Up to 40m Color Night Vision / 30m IR Night Vision
- Audio: High-gain microphone & high-volume speaker with two-way voice
- Local Storage: MicroSD card slot (Up to 512 GB)
- Power Supply: DC 12V / 1.5A (Power adapter included)
- Operating Temperature: -30°C to 50°C (-22°F to 122°F), Humidity 95% or less
Package Contents:
- 1 × EZVIZ H9c 4G Dual-Lens Pan & Tilt Camera
- 1 × Power Adapter (DC 12V / 1.5A)
- 1 × Drill Template
- 1 × Waterproof Kit
- 1 × Screw Kit
- 1 × Quick Start Guide & Regulatory Information
